UNI-P Crown

UNI-P Crown

3D printable light curing resin for temporary corrections and reconstructions of teeth

  • UNI-P Crown is a light-curing, flowable polymer based on methacrylic acid ester
    for production of 3D-printed temporary crowns, inlays, onlays, veneers, and bridges
  • UNI-P Crown may only be used in combination with the specified printers and
  • recommended equipment and in compliance with manufacturer instructions
  • UNI-P Crown is a biocompatible Class II (US) / Class IIa (EU) medical device.
  • Has outstanding mechanicel properties.
  • Thanks to advanced addatives, handshaking is sufficient to obtain a homogeneous disperson, even after long-term storage.
  • Can be easily polished and finished with glaze.
  • Available in shade A2 (Universal) and in shades A1, A3, B1 upon request.

Technical Data

  • Viscosity of 185-200 cP at 23oC.
  • Flexural strength of >100 MPa (ISO 10477:2020 and ISO 4049:2019).
  • Compressive strength of >300 MPa (ISO 9917-1:2003).
  • Flexural Modulus of >2500 MPa (ISO 10477:2020 and ISO 4049:2019).
  • Bi-axial flexural strength of >130 MPa (ISO 6872-1:2003).
  • Water sorption ≤ 40 μg/mm3 (ISO 10477:2020 and ISO 4049:2019).
  • Solubility ≤ 7.5 μg/mm3 (ISO 10477:2020 and ISO 4049:2019).
  • Depth of cure > 1.5 mm (ISO 10477:2020 and ISO 4049:2019).



Instructions for Use

EN

Infographics

  1. BJM 3DP TEMP C&B RESIN
  2. BJM 3DP C&B ASIGA MAX UV 385 Workflow
  3. BJM 3DP C&B DLP 385nm Printer Workflow

SDS

EN

Compatible 3D printers

Asiga Asiga_Logo

700700 UNI-P Crown

1 Bottle 500 ml of UNI-P Crown

700701 UNI-P Crown

1 Bottle 1 Liter of UNI-P Crown
